Ever since our establishment in 2002, we are actively indulged in manufacturing and supplying a qualitative assortment of 2.54 mm Pitch Board to Board Connectors. Made of top notch quality materials, these connectors are made available in different sizes and technical specifications. Offered products are widely used for connecting cable wires to circuit boards in safe and hassle free manner. These are highly praised and demanded among our valued clients for numerous qualities like efficient connection, strong body, and long lasting service life. We have a team of quality inspectors with us who are in charge of inspection of these 2.54 mm Pitch Board to Board Connectors on well defined parameters.
Specifications
Pitch | 2.5mm |
No. of Poles | 2 16 Pin |
Current rating | 3.0A AC/DC |
Voltage rating | 250 V AC/DC |
Contact resistance | 20m ohm.max |
Insulation resistance | 1000M ohm.Min |
Withstanding voltage | 1000V AC for one minute |
Operating temperature range | - 40°C to + 105°C |
Plating | Tin Plated |
|
![]() |
