Wire To Board Connectors

Our company provides a broad range of wire to board connectors that suit applications demanded microminiature options or elevated-power solutions. These connectors are suitable for applications in companies, for example, consumer, medical and automotive. They provide a square-post contact room, which interfaces along the male pin header via a spring-like contact. These are accessible in numerous configurations and sizes. In addition, anti-fishing choices are accessible in our wire to board connectors to safeguard the wire amid cable assembly. These connectors are used to give a powerful-force interface, guaranteeing a strong-performing contact for numerous power applications per circuit. They are obtainable in single-row and unshrouded termination styles in breakaway and solid varieties. In addition, a friction lock is accessible for a safer mating interface.

Pitch

10mm - 8mm

No. of Poles

2 - 6 Pin

Current rating

7.0A AC/DC

Voltage rating

250 V AC/DC

Contact resistance

20m ohm.max

Product Image (ITP)

3.96 mm Pitch Wire to Board Connectors

Specifications

Pitch

3.96mm

No. of Poles

2 – 20 Pin

Current rating

7.0A AC/DC

Voltage rating

250 V AC/DC

Product Image (ITP)

2.5 mm Pitch Wire to Board Connectors

Specifications

Pitch

2.5mm

No. of Poles

2 – 16 Pin

Current rating

3.0A AC/DC

Voltage rating

250 V AC/DC

Contact resistance

20m ohm.max

Product Image (ITP)

2.54 mm Pitch Wire to Board Connectors

Specifications

Pitch

2.5mm

No. of Poles

2 – 20 Pin

Current rating

3.0A AC/DC

Voltage rating

250 V AC/DC

Product Image (ITP)

7.5 mm Pitch Wire to Board Connectors

Specifications

Pitch

7.5mm – 5.0mm

No. of Poles

1 – 6 Pin

Current rating

7.0A AC/DC

Voltage rating

250 V AC/DC

Product Image (ITP)

5.08 mm Pitch Wire to Board Connectors

Specifications

Pitch

5.08mm

No. of Poles

2 – 10 Pin

Current rating

7.0A AC/DC

Voltage rating

250 V AC/DC

Contact resistance

20m ohm.max

Insulation resistance

1000M ohm.Min
